fd3051s monocrystalline silicon intelligent pressure transmitter of single flange-凯发k8国际官网

detailed introduction:

measuring range：0-6kpa-40mpa（dp）

0-6kpa-40mpa（ap）

output signal：4-20ma

accuracy class：0.25、0.1

power supply：12-42vdc

working temperature：-20—70°c（lcd）-40—70°c（oled）

communication protocol：hart/modbus

features:

● monocrystalline silicon sensor

● high-precision and high-reliability

● infrared remote control

● scene keys

● hart handhold terminal configuration

● selection of multi-kinds of remote transmission device and the filling etiquett

● selection of multi-kinds of diaphragms such as tantalum,hastelloy alloy

● selection of ptfesprayed or ptfe filmed

● installation: straight mount，side mounted or plug-in mounted

applications

the pressure and liquid level of high-temperature, corrosion and viscous medium are measured in chemical industry, metallurgical industry, petroleum and paper etc.
